Din975 Stainless Steel Round Bar Rod 304 316 JIS Iron Metal Cold Rolled 2mm
Stainless Steel Round Bar Description
Stainless steel round bars are used in a variety of machinery, mechanisms, valves, fittings, vessels, flanges, threading bars, subways, chemical and fuel tankers, signboards, escalators, elevators, lifts, and petrochemicals.
Stainless Steel Round Bar Applications
1. Food processing equipment, particularly in beer brewing, milk processing & winemaking
2. Kitchen benches, sinks, troughs, equipment and appliances
3. Architectural paneling, railings & trim
4. Chemical containers, including for transport
5. Heat Exchangers
6. Woven or welded screens for mining, quarrying & water filtration
7. Threaded fasteners
8. Springs
Stainless Steel Round Bar Specification
| Product Name | Stainless Steel Bar |
| Material | 200 series: 201, 202 |
| 300 series: 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S,309S |
| 400 series: 410, 410S,420, 430, 431, 440A,904L |
| Standard | AISI, ASTM, DIN, GB, JIS, SUS |
| Diameter | 2mm to 400 mm or 1/8” to 15” or as customer 's requirement |
| Length | 1 meters to 6 meters or as customer 's requirement |
| Treatment/Technique | Hot rolled, cold drawn, Annealed, Grinding |
| Surface | Satin,400#, 600~1000# mirrorx, HL brushed,Brushed Mirror(two kinds of finishing for one pipe) |
| Applications | Decorative /industrial/building material |
| Trade Terms | EXW, FOB, CFR, CIF |
| Delivery time | Shipped in 7-15 days after payment |
| Package | Standard sea-worthy package or as required |
| SEAWORTHY PACKING | 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM |
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM
|
Stainless Steel Round Bar Chemical Composition
| % | Cr | Ni | C | Si | Mn | P | S | Mo | Cu | Fe |
| 310 | min: 24.0
max:26.0 | min: 19.0
max: 22.0 | 0.25 | 0.75 | 2.0 | 0.045 | 0.030 | 0.75 | 0.5 | balance |
| 310S | min: 24.0
max:26.0 | min: 19.0
max: 22.0 | 0.08 | 1.00 | 2.0 | 0.045 | 0.030 | 0.75 | 0.5 | balance |
Stainless Steel Round Bar Mechanical Properties:
| Grade | Tensile Strength
ksi (min.) | Yield Strength 0.2%
Offset ksi (min.) | Elongation -
% in
50 mm (min.) | Hardness
(Brinell) MAX | Hardness
(Rockwell B) MAX |
| 310/310S | 75 | 30 | 40 | 217 | 95 |
Stainless Steel Round Bar Physical Properties:
Denstiy
lbm/in^3 | Coefficient of
Thermal Expansion (min/in)-°F | | | Electrical Resistivity mW-in | | Thermal Conductivity BTU/hr-ft-°F | | Specific Heat BTU/lbm -°F | Magnetic Permability (annealed)^1 | Modules of Elasticity (annealed)^2-psi | |
| at 68 °F | at 68 – 212°F | at 68 – 932°F | at 68 – 1832°F | at 68°F | at 1200°F | at 68 – 1832°F | at 68 – 932°F | at 32 – 212°F | at 200H | in tension (E) | in shear (G) |
| 0.29 | 8.8 | 9.5 | 10.5 | 30.7 | - | 10.5 |
CORROSION RESISTANCE:
Provides excellent corrosion resistance
High chromium content allows for good aqueous corrosion resistance
Excellent resistance at normal temperatures and also has good resistance to oxidizing and carburizing atmospheres
HEAT RESISTANCE:
- Good resistance to oxidation in intermittent service in air at temperatures up to 1040°C and 1150°C in continuous service.
- Good resistance to thermal fatigue and cyclic heating.
- Widely used where sulphur dioxide gas is encountered at elevated temperatures.
- Continuous use in 425-860°C range not recommended due to carbide precipitation, if subsequent aqueous corrosion resistance is needed
- Generally used at temperatures starting from about 800 or 900°C – above the temperatures at which 304H and 321 are effective.
Payment Terms
1.Payment: T/T, L/C, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.
2.MOQ: 1 ton
3.Warranty : 3 years
4.Package Informations: 1) EXPORT, In 20 feet (GW 25 ton) or 40 feet Container (GW 25 ton)
2)as customer's requirement
Why choose us?
(1) The leading exporter in China special steel industry.
(2) Large stocks for various sizes, fast delivery date.
(3) Good business relationship with China famous factories.
(4) More than 7 years steel exporting experience.
(5) Good after-sales service guarantee.
